Capsule primitive / Curve with Rounded Caps for Geometry Nodes

GN_Capsule.blend file contains two Geometry Nodes trees: Capsule and Capsule Adaptive

Compatible with Blender 3.1 and above.

Compatibility with 3.0 can be achieved by removing the 'Merge By Distance' node at the end of node trees. Use Weld Modifier then.

Capsule Adaptive can be used as "Curve with Rounded Caps". Add Curve modifier after GN modifier and select same Curve Object for both. Play with Adaptive Rings, Ring Spacing and Depth from Curve parameters.

Changes (2022-04-17):

• Capsule nodes use Fields now.
• Cap Profile input - Change shape of caps using power curve function.
• Weld toggle - Weld borders of geometry elements. Removes need to use Weld Modifier after this GN. Disable it if you don't need smooth shading and want to reduce computation.
• Material input - Assign a Material to geometry.
• Older version of Capsule nodes are in GN_Capsule_legacy_version.blend file. Those GN will be not compatible with Blender 3.2

License: CC0
